Four clinical CAD blocks: a 30x78in exam table drawn with its articulated sections, paper roll and hidden pedestal, an 18in five-star clinician's stool, a 96x36in nurse station with its 36in ADA accessible segment drawn as its own lowered bay, and a 72x30in laboratory bench with a reagent shelf, service turrets and an optional sink knockout. Every dimension is the one the room templates were drawn to - each block in plan to scale in inches and free to download as DXF.
4 blocks, 4 downloads on this page. DXF R2018, drawn in inches. Free, no signup.
DWG (R2000, converted from the DXF). PNG is the plan-view preview.
| Plan footprint (W x H) | 30in x 78in |
|---|---|
| Units | inches |
| DXF version | R2018 |
| Insertion datum | back-left corner on wall line (head at the wall, foot at +Y) |
| Parameter | Default | Range / options |
|---|---|---|
| Length | 78in | 66in–84in |
| Width | 30in | 24in–36in |
| Plan footprint (W x H) | 18in x 18in |
|---|---|
| Units | inches |
| DXF version | R2018 |
| Insertion datum | stool center |
| Parameter | Default | Range / options |
|---|---|---|
| Diameter | 18in | 14in–24in |
| Plan footprint (W x H) | 96in x 36in |
|---|---|
| Units | inches |
| DXF version | R2018 |
| Insertion datum | back-left corner on wall line (staff side at y=0, public at +Y) |
| Parameter | Default | Range / options |
|---|---|---|
| Length | 96in | 48in–192in |
| Depth | 36in | 30in–42in |
| Accessible Len | 36in | 36in–60in |
| Return length | 0in | 0in–60in |
| Plan footprint (W x H) | 72in x 30in |
|---|---|
| Units | inches |
| DXF version | R2018 |
| Insertion datum | back-left corner on wall line |
| Parameter | Default | Range / options |
|---|---|---|
| Length | 72in | 36in–144in |
| Depth | 30in | 24in–36in |
| Sink | false | true / false |
Standards are listed for drafting context only. A symbol drawn to a convention is not a compliance determination - verify against the governing code and the specified product. See the license and terms.
