Block family

Gym and Salon CAD Blocks

Four gym and salon CAD blocks: an 84x48in equipment station drawn with the frame rails that actually reach the floor and the access band the emergency dismount is measured from, a 96x96in free-weight lifting platform with its two rubber landing strips and boarded lifting surface, a 48x24in styling station with its mirror, tool drawers and appliance holsters, and a 30x48in shampoo bowl drawn as the bolted bowl-and-chair assembly it really is. Each drawn in plan to scale in inches and free to download as DXF.

4 blocks, 4 downloads on this page. DXF R2018, drawn in inches. Free, no signup.

84x48 Gym Equipment Station 84in x 48in

Download 84x48 Gym Equipment Station Open in editor

DWG (R2000, converted from the DXF). PNG is the plan-view preview.

84x48 Gym Equipment Station - plan view, 84in x 48in

84x48 Gym Equipment Station

Commercial Office - datum: back-left corner on wall line (access side at +Y) - default footprint 84in x 48in

Dimensions

Plan footprint (W x H)	84in x 48in
Units	inches
DXF version	R2018
Insertion datum	back-left corner on wall line (access side at +Y)

Parameters

Parameter	Default	Range / options
Width	84in	36in–120in
Depth	48in	24in–72in
Kind	selectorized	selectorized / cardio

Download

Download 84x48 Gym Equipment Station Open in editor

8x8 Free-Weight Lifting Platform

Commercial Office - datum: near-left corner of the platform - default footprint 96in x 96in

Dimensions

Plan footprint (W x H)	96in x 96in
Units	inches
DXF version	R2018
Insertion datum	near-left corner of the platform

Parameters

Parameter	Default	Range / options
Size	96in	72in–120in

Download

Download 8x8 Free-Weight Lifting Platform Open in editor

48-inch Salon Styling Station

Commercial Office - datum: back-left corner on wall line (styling chair dashed at +Y) - default footprint 48in x 24in

Dimensions

Plan footprint (W x H)	48in x 24in
Units	inches
DXF version	R2018
Insertion datum	back-left corner on wall line (styling chair dashed at +Y)

Parameters

Parameter	Default	Range / options
Width	48in	30in–72in
Depth	24in	18in–30in
Chair Dia	26in	22in–30in

Download

Download 48-inch Salon Styling Station Open in editor

Salon Shampoo Bowl and Chair

Commercial Plumbing - datum: back-left corner on the plumbing wall line (bowl at y=0, chair at +Y) - default footprint 30in x 48in

Dimensions

Plan footprint (W x H)	30in x 48in
Units	inches
DXF version	R2018
Insertion datum	back-left corner on the plumbing wall line (bowl at y=0, chair at +Y)

Parameters

Parameter	Default	Range / options
Width	30in	24in–36in
Depth	48in	40in–60in

Download

Download Salon Shampoo Bowl and Chair Open in editor

Standards are listed for drafting context only. A symbol drawn to a convention is not a compliance determination - verify against the governing code and the specified product. See the license and terms.
